Woofer AA-8NDM350

* MODEL NO.: 8NDM350
* Nominal Diameter @ inch 8
* Rated Impedance @ ohm 8
* Power Handling Capacity @ watt 350
* Program Power @ watt 700
* Sensitivity(1W/1m) @ dB 96
* Frequency Range @ Hz 95-3500
* Minimum Impedance @ ohm 6
* Voice Coil Diameter @ inch 3
* Voice Coil Material CCAW
* Voice Coil Former Material TIL
* Voice Coil Winding Depth @ mm 10
* Number of Layers 2
* Kind of Layer outside
* Gap Height @ mm 8
* Magnet Material NEO inside slug
* Magnet Size @ mm 70*8
* Basket Material Die-cast Aluminium
* Cone Material Semi press pulp
* Cone Design Curved
* Surround Material Polycotton
* Surround Design M – roll
